This shows the simulation of an RLC circuit powered by a 1 kHz AC source. The graph illustrates the current waveforms through the resistor (orange), inductor (blue), and capacitor (green), along with the total circuit current (red). Each component exhibits a distinct phase relationship: the inductor current lags, the capacitor current leads, and the resistor current remains in phase with voltage. This highlights the dynamic interplay of reactance in AC circuits. #ElectronicsEducation #electronic
