This simulation demonstrates how different colors can be produced using an RGB LED by driving its Red, Green, and Blue terminals with separate square wave signals. Each channel is controlled by a pulse generator through a current-limiting resistor, and the waveforms at the top show the timing of the applied signals. By varying the duty cycles and the phase relationships of these signals, the LED can generate multiple color combinations through additive mixing of red, green, and blue light. In th

This simulation demonstrates the working of an RGB LED driven by different input signals to produce multiple colors. Each of the three LEDs inside the RGB package—Red, Green, and Blue—is powered through separate signal sources that generate triangular waveforms. By varying the intensity of each color through these waveforms, the LED mixes them to create different color outputs. For example, turning on only the Blue section gives blue light, while combining Green and Red produces yellow, and acti
